【攻防世界】Moblie系列之Android2.0

【攻防世界】Mobile系列之Android2.0

反编译获取原代码，定义MainActivity类，找到判断关键代码

ublic void onClick(View v) {
                MainActivity.this.Show(JNI.getResult(MainActivity.this.pwd.getText().toString()));
            }

这里调用了JNI.getresult函数，跟进该函数

public class JNI {
    public static native int getResult(String str);

    static {
        System.loadLibrary("Native");
    }
}

这里调用了Native层的so文件Native.so，我们使用IDA打开该文件，定位Java_com_example_test_ctf03_JNI_getResult反编译获取伪代码

bool __fastcall Java_com_example_test_ctf03_JNI_getResult(int a1, int a2, int a3)
{
  _BOOL4 v3; // r4
  const char *v4; // r8
  char *v5; // r6
  char *v6; // r4
  char *v7; // r5
  int i; // r0
  int j; // r0

  v3 = 0;
  v4 = (const char *)(*(int (__fastcall **)(int, int, _DWORD))(*(_DWORD *)a1 + 676))(a1, a3, 0);
  if ( strlen(v4) == 15 )
  {
    v5 = (char *)malloc(1u);
    v6 = (char *)malloc(1u);
    v7 = (char *)malloc(1u);
    Init(v5, v6, v7, v4, 15);//将字符串分为a1,a2,a3
    if ( !First(v5) )
      goto LABEL_6;
    for ( i = 0; i != 4; ++i )
      v6[i] ^= v5[i];
    if ( !strcmp(v6, a5) )
    {
      for ( j = 0; j != 4; ++j )
        v7[j] ^= v6[j];
      v3 = strcmp(v7, "AFBo}") == 0;
    }
    else
    {
LABEL_6:
      v3 = 0;
    }
  }
  return v3;
}

上面的代码中有几个调用的函数，init()、First()函数，我们来一一分析下这两个函数

int __fastcall Init(int result, char *a2, char *a3, const char *a4, int a5)
{
  int v5; // r5
  int v6; // r10
  int v7; // r6

  if ( a5 < 1 )
  {
    v6 = 0;
  }
  else
  {
    v5 = 0;
    v6 = 0;
    do
    {
      v7 = v5 % 3;
      if ( v5 % 3 == 2 )
      {
        a3[v5 / 3u] = a4[v5];
      }
      else if ( v7 == 1 )
      {
        a2[v5 / 3u] = a4[v5];
      }
      else if ( !v7 )
      {
        ++v6;
        *(_BYTE *)(result + v5 / 3u) = a4[v5];
      }
      ++v5;
    }
    while ( a5 != v5 );
  }
  *(_BYTE *)(result + v6) = 0;
  a2[v6] = 0;
  a3[v6] = 0;
  return result;
}

上面的代码逻辑是将字符串分为三个部分，依次按照a1,a2,a3的顺序来保存

接下来看看First()函数的代码，这里是将a1的字符进行运算后与常量”LN^dl”作比较

bool __fastcall First(char *a1)
{
  int i; // r1

  for ( i = 0; i != 4; ++i )
    a1[i] = (2 * a1[i]) ^ 0x80;
  return strcmp(a1, "LN^dl") == 0;
}

这里可以对该代码进行逆向倒推出满足该程序的字符串，代码如下

def re_first():
    b = "LN^d1"
    a1 = ''
    for i in range(0,4):
        print(i)
        a1 += chr(int((ord(b[i])^0x80)/2))
    a1+='1'
    print(a1)

if __name__=='__main__':
    re_first()

得到a1原来的值为fgor1，但经过该函数的调用后a1变为了”LN^d1“，接下来对a2和a3进行了变换

for ( i = 0; i != 4; ++i )
      v6[i] ^= v5[i];
    if ( !strcmp(v6, a5) )//v6=a5，a5=" 5-"+0x16+"a"
    {
      for ( j = 0; j != 4; ++j )
        v7[j] ^= v6[j];
      v3 = strcmp(v7, "AFBo}") == 0;
    }

对a2和a3进行逆向反推获取原来的字符串，代码如下

def re_second():
    a5 = [ord(' '),ord('5'),ord('-'),0x16,ord('a')]
    v5 = [ord('L'),ord('N'),ord('^'),ord('d'),ord('1')]
    v6 = ''
    for i in range(0,4):
        v6 += chr(a5[i]^v5[i])
    v6+='a'
    print(v6)

def re_thrid():
    v6 = [ord(' '),ord('5'),ord('-'),0x16,ord('a')]
    a = "AFBo"
    v7 = ''
    for i in range(0,4):
        v7 += chr(v6[i]^ord(a[i]))
    v7 += ”}“
    print(v7)

得到原来的a2为 ”l{sra“ a3为”asyo}“

到这里就得到了a1,a2和a3变换后的值，根据最上面的init()逆向分析将这三个变量进行拼接，代码如下

def re_str():
    a1 = 'fgor1'
    a2 = 'l{sra'
    a3 = 'asoy}'
    flag = ''
    for i in range(5):
        flag += a1[i]+a2[i]+a3[i]
    print(flag)

最后得到正确的字符串flag{sosorry1a}
